Radio Set SCR-300-A BC-1000-A
Year 1943

Radio Set SCR-300-A BC-1000-A consists of an 18 tubes, low power, dry battery operated, portable radio receiver and transmitter and accessories. It is designed for frequency modulated, two way communication over short distances. It is primarily intended as a walkie talkie for foot combat troops. However, it is also readily adaptablefor fixed station use. The complete radioinstallation weighs only 38.23 pounds with Battery BA-70, or 32.23 pounds with Battery BA-80.







Radio Set SCR-300-A BC-1000-A


Freq. cov.: 40.0 to 48.0 Mc
Mode: f-m voice
Type of
modulation:		 Frequency modulation
Type of
transmitter:		 f-m reactance modulated
Type of receiver: f-m double suprheterodyne
Distance range: 3 miles
Pwr output: 0.3 W
Tubes: 2 x 3A4
6 x 1T4
5 x 1L4
1 x 1R5
1 x 1A3
3 x 1S5
Power supply: dry battery BA-70 or BA-80
6-12-24V in vehiculars use
with Vibrator Power Supply
PP-114
